The diagram of language change page
3 3 2 2 Setting IP Address. . .
(1) Click the Web management page
menu bar “IP”, then It will popup a
dialog box of setting IP address.
3.3.2 Operating Instruction of Web
3 3 2 1 Change Language. . .
As shown in the picture below, press the drop-down list at the icon , choose
“Chinese” or “English” to achieve Web page language, as the picture below.
(2) Change product IP address, subnet
mask and gateway at the dialog box of
setting IP address, such as change the
IP address to 192.168.2.200, keep
subnet mask unchanged, and change
default gateway to 192.168.2.1.
(3) After changing the IP address, press the “OK” button and wait for 10 seconds
till product IP address is successfully changed.
13 14
After inputting the correct user name and password, click <Login> and the
browser will show the product Web management page as the picture below:
Please follow the steps to check if the injector is installed correctly:
(1) Whether the physical connection of the equipment is correct?
The other end of the network line that is connected with computer
network card must connect with the injector Console port, and ensure the
link indicator light of the network port is on.
(2) Whether the computer TCP/IP agreement setting is correct?
Your computer’s IP address must be 192.168.1.x (x range is1~254
and x cannot be 200, it will conflict with the product IP
address: 192.168.1.200), subnet mask: 255.255.255.0
otherwise
.
Caution
Diagram of Web English management page
