GYS STARTIUM 680E - Selecting charge speed; Selecting battery type; Starting the charge; Charge progression

16
STARTIUM 330E / 480E / 680E / 980E
EN
Translation of the original instructions
a. Select the charge speed ( - 13) with respect to the battery capacity (see table below).
STARTIUM 330E STARTIUM 480E STARTIUM 680E STARTIUM 980E
12V 24V 12V 24V 12V 24V 12V 24V
Charge 1
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
20-75Ah
(5A)
Charge 2
40-150Ah
(10A)
40-150Ah
(10A)
60-225Ah
(15A)
40-150Ah
(10A)
60-225Ah
(15A)
60-225Ah
(15A)
85-300Ah
(20A)
60-225Ah
(15A)
Charge 3
60-225Ah
(15A)
60-225Ah
(15A)
130-450Ah
(30A)
60-225Ah
(15A)
130-450Ah
(30A)
100-375Ah
(25A)
170-600Ah
(40A)
130-450Ah
(30A)
Charge 4
100-375Ah
(25A)
85-300Ah
(20A)
170-600Ah
(40A) (boost)
130-450Ah
(30A) (boost)
200-675Ah
(45A) (boost)
150-525Ah
(35A) (boost)
210-750Ah
(50A) (boost)
150-525Ah
(35A) (boost)
b. Choose the battery type ( - 12) : Liquide, Gel, AGM, Start/Stop . In the event that the battery type is unknown
(Liquid, Gel, AGM, Start/Stop), select the UNIVERSAL mode.
3. Press the START/STOP button (
- 9) to start the charge.
Three indicators show that the battery is charging :
- The charge LED ( - 7).
- The display (2) : It alternates between the battery voltage and the percentage of charge (an evolution of both
values should be noticed).
- The voltage and percentage LEDs (4 and 5). They remain on and alternate at the same time as the display.
The charge progression is shown in percentage (%).
% Battery charge level Phase
0% Battery charge level Testing phase
25% Charge start
Boost
50%
Charge at 50%
75% Charging the remaining % Absorption
100%
Charged battery Floating
4. Blocked and charge stop.
The battery charge does not start when :
- The battery voltage is inferior to 1V.
- The battery voltage does not match the voltage that is selected on the charger.
The battery charge stops when :
- The START/STOP button is pressed again.
- The continuous charge duration reaches 16h.
Once the battery is charged, the STARTIUM performs a oating/maintenance charge. The charge does
not stop to compensate for self-discharge and maintain the battery at a 100%.
If it is a sealed battery and if the liquid boils, it means the battery is damaged. Is this occurs, it is
recommanded to stop the charge to prevent any risk of explosion.
- The charger will stop if the « automatic restart » has not been activated.
5. Charger mode functions
a. Automatic restart feature:
In the event of a power cut :
- During a normal charge, the STARTIUM switches off. When it switches back on, it does not resume the charge. It
must be manually resumed.
- During a charge with the «Automatic restart» feature on, the STARTIUM switches off. When it switches back on, it
automatically resumes the charge.
To use the «Automatic restart» mode :
- Perform steps 1 and 2 of normal loading.
- When starting the charge (step 3), press the START/STOP button ( - 9) for a long time (> 5 sec.). ( - 9).
