3
Item
项目
Specifications
规格
HVDC input
高压直流输入
Rated input voltage range
额定输入电压范围
240V DC
Max input voltage range
最大输入电压范围
180 to 320 VDC
Max input current
最大输入电流
10 A
Output voltage
输出电压
56 V
Max output current
最大输出电流
AC:
17 A: 90 to 176 VAC @ 47 to
63 Hz
29 A: 176 to 290 VAC @ 47 to
63 Hz
DC: 29 A
Max output power
最大输出功率
AC:
950 W: 90 to 176 VAC @ 47
to 63 Hz
1600 W: 176 to 290 VAC @
47 to 63 Hz
DC: 1600 W
Dimensions (H × W × D)
外形尺寸(高
×
×
深)
40.2 × 73.5 × 185 mm (1.58 × 2.89 × 7.28 in)
Weight
重量
1 kg (2.20 lb)
Operating temperature
工作温度
10°C to +55°C (14°F to 131°F)
Relative humidity
工作环境相对湿度(非凝露)
5% RH to 95% RH, noncondensing
Storage temperature
存储温度
-40°C to +70°C (40°F to +158°F)
LEDs
电源模块状态指示灯
The PSR1600-54A-B power supply provides two LEDs on its faceplate to indicate
the power input and output status. PSR1600-54A-B 电源模块面板上有两个电源模
块指示灯,用于指示电源的输入、输出状态。
LED
指示灯
Mark
面板标示
Status
Description
含义
Output status LED
输出状态指示灯
OUT OK
Steady green
绿色常亮
Normal power output.
输出正常
Steady red
红色常亮
Abnormal power output.
输出异常
