H3C S5120-EI Series - Combo Port

1-10
Transceiver
Central
wavelength
Connector Fiber/Cable
Max
transmission
distance
SFP-GE-LX-
SM1310-BIDI
TX: 1310 nm
RX: 1490 nm
SFP-GE-LX-
SM1490-BIDI
Note that
these two
transceive
rs should
be used in
pairs.
TX: 1490 nm
RX: 1310 nm
LC
9/125 µm single mode
optical fiber
10 km
(6.21 mi)
z You are recommended to use SFP transceivers of H3C on the S5120-EI series.
z The S5120-EI series Ethernet switches support GE SFP transceivers only.
z The types of SFP transceivers may update with time. For information about transceivers, contact
H3C technical support or marketing staff.
z For the models and specifications of each kind of transceivers, refer to H3C Low End Series
Ethernet Switches Pluggable Modules Manual.
Combo Port
Each SFP port and the corresponding 10/100/1000Base-T Ethernet port form a Combo port. For each
Combo port, either the SFP port or the corresponding 10/100/1000Base-T Ethernet port can be used at
a time. For details about the combo port mapping relationship, please refer to
Table 1-5.
Table 1-5 Combo port mapping relationship
Model SFP port 10/100/1000Base-T Ethernet port
GigabitEthernet1/0/25 GigabitEthernet1/0/22
GigabitEthernet1/0/26 GigabitEthernet1/0/24
GigabitEthernet1/0/27 GigabitEthernet1/0/21
S5120-28C-EI
S5120-28C-PWR-EI
S5120-24P-EI
GigabitEthernet1/0/28 GigabitEthernet1/0/23
GigabitEthernet1/0/49 GigabitEthernet1/0/46
GigabitEthernet1/0/50 GigabitEthernet1/0/48
GigabitEthernet1/0/51 GigabitEthernet1/0/45
S5120-52C-EI
S5120-52C-PWR-EI
S5120-48P-EI
GigabitEthernet1/0/52 GigabitEthernet1/0/47
The SFP port and its corresponding 10/100/1000Base-T autosensing Ethernet port cannot be used
together at the same time. For details, refer to the Ethernet Port Configuration part in the Access
Volume of the H3C S5120-EI Series Ethernet Switches Operation Manual.
