2-14
Figure2-19 Installing a power supply
Removing a CA-70A12, PSR75-12A, or PSR150-D1 power
supply
The removal procedure is the same for the CA-70A12, PSR75-12A, and PSR150-D1 power supplies.
The following procedure removes a PSR75-12A power supply.
To remove a PSR75-12A power supply:
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Disconnect the power cord.
3. Loosen the captive screws on the power supply with a Phillips screwdriver until they are
completely disengaged.
4. Grasp the handle of the power supply with one hand and pull it out a little, support the bottom
with the other hand, and pull the power supply slowly along the guide rails out of the slot.
Put away the removed power supply in an antistatic bag or the power supply package bag for
future use.
Figure2-20 Removing a power supply
