Figure2-1 Firewall installation flow
Mounting the firewall on a workbench
Ensure good ventilation and a minimum clearance of 80 mm (3.15 in)
around the chassis for heat
dissipation.
• Avoid placing heavy objects on the firewall.
If a standard 19-inch rack is not available, you can place the firewall on a workbench.
To mount the firewall on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.
End
Determine the
installation position
Mount the firewall on a
workbench
Mount the firewall in a
19-inch rack
Ground the firewall
Install interface modules
Connect interface
cables
Connect power cords
Verify the installation
Install power supplies
Start
Install drives
To Next Page
