H3C SecPath F50X0 Series Installation Manual

15
Figure2-10 Mounting the firewall in the rack (with the wide flange of the rear mounting
brackets inside the rack)
Figure2-11 Mounting the firewall in the rack (with the wide flange of the rear mounting
brackets outside the rack)
Grounding the firewall
WARNING
!
•
Correctly connecting the firewall grounding cable is crucial to lightning protection and EMI
protection.
• Do not connect the firewall grounding cable to a fire main or lightning rod.
