H3C SecPath F50X0 Series Installation Manual

12
Figure2-3 Installing cage nuts
5. Attach the front mounting brackets to both sides of the firewall with M4 screws provided with the
firewall.
Figure2-4 Attaching the front mounting brackets to the firewall
6. Mount the firewall in the rack. Use M6 screws to secure the mounting brackets to the front rack
posts.
Figure2-5 Mounting the firewall in the rack
1
2
3
