H3C WA Series Installation Guide

4
1 Product overview
The H3C WA2600 Series Enhanced WLAN Access Points (WA2600 enhanced series) are
one of the 802.11n access point (AP) product series developed by Hangzhou H3C
Technologies Co., Ltd. (H3C).
Introduction
The WA2600 enhanced series includes the WA2610E-AGN and WA2620E-AGN access
points and can serve as FIT APs to cooperate with wireless local area network (WLAN)
switches or access controllers to provide wireless access for WLAN users.
Figure 1shows a typical scenario of hotspot deployments using the WA2600 enhanced
series.
Figure 1 Configuration of the WA2600 enhanced series on hotspots (fit AP mode)
For the WA2600 enhanced series, see Figure 2
WA2600
WA2600
WA2600
WA2600
Core equipment
room
Radius server
Wireless NMS
AC
Switch
Switch
Switch
Switch
Switch
Auditorium
Restaurant or
tea house
Hall or information
desk
Parking lot
PC
PC
PC
PC
