14-24
z When you log in to an AP by using the scheme authentication mode, your access rights depend on
your user level defined in the AAA scheme.
z When the local authentication mode is used, the user levels are specified using the
authorization-attribute level level command.
z When the RADIUS authentication mode is used, the user levels are set on the corresponding
RADIUS servers.
For more information about AAA and RADIUS, see AAA in the Security Configuration Guide.
Displaying Web Users
Follow the step below to display information about Web users:
To do… Use the command… Remarks
Display information about Web users
display web users
Available in any view
Configuration Example
Step1 Log in to the AP through the console port and assign an IP address to VLAN-interface 1 of the AP. By
default, VLAN 1 is the management VLAN.
z Connect to the console port. See Logging In Through the Console Port.
z Execute the following commands in the terminal window to assign an IP address to VLAN-interface
1 of the AP.
# Configure the IP address of the management VLAN interface as 10.153.17.82 with the mask
255.255.255.0.
<Sysname> system-view
[Sysname] interface vlan-interface 1
[Sysname-Vlan-interface1] ip address 10.153.17.82 255.255.255.0
Step2 Configure the user name and the password for the web-based network management system.
# Configure the user name as admin, the password as admin, and command level as 3.
[Sysname] local-user admin
[Sysname-luser-admin] password simple admin
[Sysname-luser-admin] authorization-attribute level 3
[Sysname-luser-admin] service-type telnet
Step3 Establish an HTTP connection between your PC and the AP, as shown in the following figure.
Figure 14-16 Establish an HTTP connection between your PC and the AP
