10-8
Figure 10-2 Network diagram for remote upgrade
Internet
Telnet
FTP Server
2.2.2.2/24
User
FTP Client
AP
1.1.1.1/24
Configuration procedure
z Configuration on FTP Server (Note that configurations may vary with different types of servers)
# Enable FTP Server.
<FTP-Server> system-view
[FTP-Server] ftp server enable
# Set the FTP username to aaa and password to hello.
[FTP-Server] local-user aaa
[FTP-Server-luser-aaa] password cipher hello
# Configure the user to have access to the aaa directory.
[FTP-Server-luser-aaa] level 3
[FTP-Server-luser-aaa] service-type ftp
[FTP-Server-luser-aaa] work-directory flash:/aaa
z Configuration on AP
If the size of the Flash on the AP is not large enough, delete the original application programs from the
Flash before downloading.
# Enter the following command in user view to log in to FTP Server.
<AP> ftp 2.2.2.2
Trying ...
Press CTRL+K to abort
Connected.
220 WFTPD 2.0 service (by Texas Imperial Software) ready for new user
User(none): aaa
331 Give me your password, please
Password:
230 Logged in successfully
[ftp]
# Download the test.bin and boot.btm programs on FTP Server to the Flash of AP.
