H3C WA2600 series - Figure 1-3 Leds on the H3 C WA2610 E-AGN; Figure 1-4 Leds on the H3 C WA2620 E-AGN; Leds

1-3
Model Protocols and chassis material
H3C WA2620E-AGN
IEEE 802.11a/b/g/n, dual-RF, sheet
metal
The following describes the hardware configurations and functions of
the WA2600 series in detail.
LEDs
The positions and identifications of LEDs on the panel vary with the
models. For details about these LEDs, see
Table 1-3.
H3C WA2610E-AGN
Figure 1-3 LEDs on the H3C WA2610E-AGN
H3C WA2620E-AGN
Figure 1-4 LEDs on the H3C WA2620E-AGN
