1-1
1 Appendix A AP view and technical
specifications
AP view
Figure1-1 WA6520
Technical specifications
Table1-1 Technical specifications for the WA6520
Dimensions (H × W × D) 32 × 180 × 180 mm (1.26 × 7.09 × 7.09 in), mounting bracket excluded
System power consumption ≤ 13 W
Antenna
Built-in antenna:
• 2.4 G: 3 dBi gain
• 5 G: 4 dBi gain
Power supply
• DC power supply
• PoE power supply: complies with IEEE802.3af
Protocol
• IEEE802.11a/b/g/n/ac/ax
• IEEE802.3af
