H3C WX User Manual

6-1
6 Access Controller Module Basic Configuration
Access Controller Module Basic Configuration
An access controller module installed in the expansion slot on the switch is connected to the switch
through internal ports of the switch. To enable the H3C S7500/S7500E/S9500 switch to collaborate with
the module, you need to configure the ports on the switch.
Before configuration, make sure that your switch has been installed with the following:
z SRPU
z I/O module
z Access controller module
Perform the following configuration on the switch:
z Configure the two internal ports connecting the access controller module and permitted VLANs on
the ports.
z Aggregate the two internal ports of the switch.
Configuring the Internal Ports of the Switch
Follow these steps to configure the internal ports of the switch:
To do… Use the command… Remarks
Enter system view
system-view
—
Create VLANs and enter VLAN
view
vlan
{ vlan-id1 [
to
vlan-id2 ] |
all
} Required
Exit from VLAN view
quit
—
Create a manual aggregation
group
link-aggregation group
agg-id
mode manual
Required
The LSQM1WCMB0 and the
LSBM1WCM2A0 do not support
creating or configuring aggregation
groups.
Enter Ethernet port view
interface
interface-type
interface-number
—
Set the link type of the port to trunk
port link-type trunk
Required
Set the default VLAN on the trunk
port
port trunk pvid vlan
vlan-id
Optional
The default VLAN of the trunk port
is the system default VLAN.
Add the port to the aggregation
group
port link-aggregation group
agg-id
Required
Ports on the LSQM1WCMB0 and
the LSBM1WCM2A0 cannot be
added to aggregation groups.
