6-4

You can create VLANs on the Ten-GigabitEthernet interface connecting the switch and the access

controller module LSQM1WCMB0, LSBM1WCM2A0, or LSRM1WCM2A1, and then configure the port

of the switch.

Configuration procedure

1) Configure the switch

<Switch>system-view

# Create VLAN 8 through VLAN 10.

[Switch]vlan 8 to 10

# Configure the port of the switch.

[Switch]interface Ten-gigabitethernet4/0/1

[Switch-Ten-GigabitEthernet4/0/1]port link-type trunk

[Switch-Ten-GigabitEthernet4/0/1]port trunk permit vlan 8 to 10

2) Configure the access controller module.

<Switch>oap connect slot4

<AC>system-view

# Create VLAN 8 through VLAN 10.

[AC]vlan 8 to 10

# Configure the port of the access controller module.

[AC]interface Ten-gigabitethernet 1/0/1

[AC-Ten-GigabitEthernet1/0/1]port link-type trunk

[AC-Ten-GigabitEthernet1/0/1]port trunk permit vlan 8 to 10

Configuring LSWM1WCM20 or LSWM1WCM10

Network requirements

An access controller module LSWM1WCM20 or LSWM1WCM10 is inserted in the switch. Packets on

VLAN 1, and VLAN 8 through VLAN 10 are permitted to transfer between the switch and the module. By

default, packets on VLAN 1 are permitted to transfer between the module and the switch.

z For access controller module LSWM1WCM20, you need to first aggregate the two GigabitEthernet

ports connecting the switch and the access controller module, create VLANs on the aggregation

port, and then configure the port of the switch.

z You can create VLANs on the Ten-GigabitEthernet interface connecting the switch and the access

controller module LSQM1WCMB0, LSBM1WCM2A0, or LSRM1WCM2A1, and then configure the

port of the switch.

Configuration procedure

1) Configure the switch
