H3C WX User Manual

6-2
z The numbers of the internal ports connecting the access controller module are related to the slot
where the access controller module is seated. For example, in slot 2, the two internal ports are
numbered GE 2/0/1 and GE 2/0/2.
z The manual link aggregation approach must be adopted.
z For the configuration commands of the switch, refer to the user manual of the switch.
Configuring the Access Controller Module
In order for the access controller module to collaborate with the switch, you need to do some
configuration on the module. The access controller module is connected to the switch through the
internal port (a GigabitEthernet or Ten-GigabitEthernet interface).
Follow these steps to configure the access controller module:
To do… Use the command… Remarks
Enter system view
system-view
—
Create VLANs and enter VLAN
view
vlan
{ vlan-id1 [
to
vlan-id2 ] |
all
} Required
Exit from VLAN view
quit
—
Enter Ethernet interface view
interface
interface-type
interface-number
—
Set the link type of the port to trunk
port link-type trunk
Required
Permit the specified VLANs to pass
the trunk port
port trunk permit vlan
{ vlan-id-list |
all
}
Required
By default, the trunk port permits
only VLAN 1 to pass.
Set the default VLAN on the trunk
port
port trunk pvid vlan
vlan-id
Optional
By default, the default VLAN of a
trunk port is VLAN 1.
For more information about the vlan, port link-type trunk, port trunk permit vlan, port trunk permit
vlan, and port trunk pvid vlan commands, see VLAN in the Layer 2 – LAN Switching Command
Reference.
