6
MAD status : Normal
Member ID Port MAD status
1 Ten-GigabitEthernet1/0/10 Normal
2 Ten-GigabitEthernet2/0/10 Normal
Table 5 Command output
Field Description
Multi-active recovery state
Whether the IRF fabric is in Recovery state:
Yes—The IRF fabric is in Recovery state. When MAD detects that an IRF
fabric has split into multiple IRF fabrics, it allows one fabric to forward
traffic. All the other IRF fabrics are set to the Recovery state. In Recovery
state, MAD shuts down all network interfaces in the fabric except for the
IRF network interfaces and interfaces configured to not shut down.
No—The IRF fabric is not in Recovery state. It is active and can forward
traffic.
Excluded
ports(user-configured)
Interfaces manually configured to not shut down when the IRF fabric transits
to the Recovery state.
Excluded
ports(system-configured)
Interfaces set to not shut down by default when the IRF fabric transits to the
Recovery state. These interfaces are not user configurable.
MAD status
LACP MAD operating status:
Normal—LACP MAD is operating correctly.
Faulty—LACP MAD is not operating correctly. Verify the following items:
{ The aggregate interface for LACP MAD is up.
{ The intermediate device supports extended LACPDUs for MAD.
{ All member devices have ports assigned to the link aggregation
group for LACP MAD.
Member ID IRF member ID of the local device.
Port Member ports of the aggregate interface used for LACP MAD.
MAD status
LACP MAD operating status on a member port:
Normal—LACP MAD is operating correctly.
Faulty—LACP MAD is not operating correctly.
irf auto-merge enable
Use irf auto-merge enable to enable IRF auto-merge.
Use undo irf auto-merge enable to disable IRF auto-merge.
Syntax
irf auto-merge enable
undo irf auto-merge enable
Default
IRF auto-merge is enabled.
Views
System view
Predefined user roles
network-admin
