Haas VF-2

30
INSTALLATION
June 1999
96-8000
ANCHOR P ATTERN FOR VF-8/9/11
94. 00
238.8 cm
42.00
106.7 cm
60
111.2 cm
MACHINE
FRONT
57.75
146.7 cm
Note: Foundation must extend at
least 1ft. from bored holes.
Machines with outriggers must have
the foundation extend at least 1 ft. from
the outrigger leveling pads.
24.00
61.0 cm
60
111.2 cm
50.00
127.0 cm
81.00
205.7 c
m
73.00
127.0 cm
201.50
511.8 cm
FOUNDATION LINE
OUTRIGGER FOOT
