291
PARAMETERS
June 1999
96-8000
MCD RLY BRD If set to 1, adds 8 additional relays, for a total of 40. These additional
relays (M21-M28) become available on a secondary board, and are
shown on the discrete outputs page.
TSC ENABLE When set to 1, "DSBL CLNT IN" bit is ignored, M24, M54 and M64
are disabled, and TSC will operate. When set to zero, the control
functions normally.
AUX JOG NACC If the jog handle is moved rapidly the auxillary axis will not develope
extremely large lags.
ALISM PRGRST Alias M codes during program restart.
DSBL JOG TST Disables the encoder test for the jog handle.
AIR DR @ M24 Used on horizontal mills only.
P RDY @ Y160 Used on horizontal mills only.
APC ENABLED Mills with an Automatic Pallet Changer, this bit must be set to 1. For
all other mills, it must be set to 0
SPNDL NOWAIT When (1), the machine will not wait for the spindle to come up to
speed immediately after an M03 or M04 command. Instead, it will
check and/or wait for the spindle to come up to speed immediately
before the next interpolated motion is initiated. This bit does not
affect rigid tapping or the TSC option.
Parameter 210 X AXIS TOOL CHANGE OFFSET
Used on the HS-2RP mill for X axis displacement from the home position to tool change
position.
If this parameter contains an incorrect value, a horizontal mill will crash when it does a tool
change.
Parameter 211 Y AXIS TOOL CHANGE OFFSET
Used on the HS-2RP mill for Y axis displacement from the home position to tool change
position.
If this parameter contains an incorrect value, a horizontal mill will crash when it does a tool
change.
Parameter 214 D:Y CURRENT RATIO %. UNIT: %.
This parameter is used with the Vector Drive. This defines the ratio between the two winding
configurations. This default winding is Y, and the parameters are set for the Y winding. This
number is used to adjust the parameters for the delta winding when the windings are switched.
If a Vector Drive is not installed, this parameter is called C axis TOOL CHANGE OFFSET, and
is not used.
Parameter 215 CAROUSEL OFFSET
Used on horizontal mills only. Parameter used to align tool 1 of tool changing carousel
precisely. Units are encoder steps.
Parameter 216 CNVYR RELAY DELAY
Delay time in 1/50 seconds required on conveyor relays before another action can be
commanded. Default is 50.
