English 77
5. Insert the test cuvette.
The measurement starts automatically.
The result of the color calculation is displayed.
Note: The bar on the right next to the result shows the result relative
to the measurement range.
6. For the next measurement, remove the cuvette and insert the next
sample cuvette, or press Measure to measure the same sample
again.
Touch-sensitive areas in measurement mode
In measurement mode, there are touch-sensitive areas that give you
immediate access to various menu options.
Figure 3 Touch-sensitive areas in measurement mode
Parameter setup options
Press Options to set up the parameter.
1 Open Select Color Scale, and select the scale for the display.
2 Change the displayed color scale to the next color system which is selected
in the Operator ID color scale list for display.
3 OpenSample ID to change or add the sample ID.
4 Change the Upper Limit of the color range.
5 Change the Lower Limit of the color range.
6 Open Comments to enter a comment.
