Figure 1 Product overview
1 Probe 3 Probe cable
2 Measuring path with wiper
2.6 Product components
Make sure that all components have been received. Refer to Figure 2. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 NT3100sc or NT3200sc 3 Wiper blade
9
5 mm (5x)
2 Wiper blade
9
1 mm or 2 mm (5x) 4 LZY261—Screw set, probe adapter for pole mount
9
The wiper type depends on the probe version.
English 9
