Brushless DC Controller HST-350
Orginalbetriebsanleitung Rev1.3
8 CAN High CAN_P < 36 CAN Bus
9 CAN Low CAN_N < 36 CAN Bus
10 activation
bootloader 1
Boot_34 5 input (Digital) Internal function
11 activation
bootloader 2
Boot_69 5 input (Digital) Internal function
12 switch for brake In_Brake 5 input (Digital)
13 Reverse Reverse direction
of rotation
5 input (Digital)
14 signal Ground GND 5 GND 10 pole 1 /brown
15 pedal position
sensor 1
PVS_1 5 input (analog)
16 pedal position
sensor 2
PVS_1 5 input (analog)
17 signal ground GND 0 GND
18 PWM output control
signal
o_in_PWM 5 input (Digital)
19 PWM output control
signal
o_in_PWM 5 output (Digital)
20 TxD TxD_Wireless 5 Transmit data
UART
Internal function
21 RxD RxD_Wireless 5 Receive data
UART
Internal function
22 power supply
HST350 steady
state
V_Bat accumulator
32– 58.8
Power supply relay 150A V_Bat 5/ red
23 Relay control (-) coil RLY_Bridge V_Bat - 12 output (load) Relaiy (-)-coil
24 Hall sensor 1
(120° commutation)
Hall_1 5 input (digital) 10 pole 7 / yellow
25 Hall sensor 2
(120° commutation)
Hall_2 5 input (digital) 10 pole 2 /blue
26 Hall sensor 3
(120° commutation)
Hall_3 5 input (digital) 10 pole 3/dark
gray
27 supply 5V +5V_Track1 5 +5V supply (max.
30 mAh)
28 Hall sensor 1a
(180° commutation)
Hall_1a 5 input (digital) Internal function
29 Hall sensor 2a
(180° commutation)
Hall_2a 5 input (digital) Internal function
30 Hall sensor 3a
(180° commutation)
Hall_3a 5 input (digital) Internal function
31 CAN 2 H CAN <36 CAN Bus Internal function
32 CAN 2 L CAN >36 CAN Bus Internal function
33 signal ground* ISO GND 0 isolated GND *geht nicht für
Std.-GND
34 fan-control FAN -- output (load)
35 Power supply 5V of
Hall sensors
(pin24-26,28-30)
+5V_Track2 5 +5V power supply 10 pole 6 / red
Montage und Inbetriebnahme
