Total
Harmonic
.005%, 20Hz-20kHz @ 2 volts RMS
Distortion
&
Noise:
Sensitivity: (For 0.5 V RMS Output): 75 mV RMS
Signal to
Noise
-97dB (A-weighted, relative to 2.0 V RMS)
Ratio:
Input Impedance:
15-28k
Ohms
Gain:
I
+20dB
Output
Line Out: 316 ohms
Impedance:
Record Out: 2150 ohms
GENERAL
Inputs
Phono (Mv/MM), CD, Tuner, Video, Aux
1,
Aux 2,
Tape 1,Tape 2,EPL In
Outputs:
Record
1,
Record 2, EPL Out, Line
Controls: input Selectors, Phono gain, Mute/Normal, Record Send 1,
Record Send 2, Tape Monitor 1, Tape Monitor 2, External
Processor Loop engage, Mono, Balance, Volume, Power
convenience (Polarized) 1
Unswitched, 2 Switched, 5 amp continuous,
Outlets: 72 amp surge
Size:
17” wide x 3” high
x
8
1/2”
deep
TRANSMITTER
Controls:
Input Selectors (or as redefined when IRIS compatible unit(s)
are present),
SX/Clear,
Mute/Normal, Volume
&
Balance Knobs
Size:
2
7/8”
wide, 11 1/2” high, 7 1/2” long
Batteries: 4
x
AA Alkaline
17
