Hafler IRIS - Specifications

IRIS SPECIFICATIONS
Phono Section:
Frequency
Response:
Maximum
Output Voltage:
Totul
Harmonic
Distortion &
Noise
Sensitivity:
Signal to Noise
Ratio:
Maximum Input
Signal:
Input Impedance:
Gain:
LINE SECTION
Frequency
Response:
Bandwidth:
Maximum
Output Voltage:
(Measurements at REC OUT)
20Hz-20kHz,
±0.1 dB
5 Volts RMS, 20Hz-20kHz
20Hz-20kHz
Moving Magnet: .002%
Moving Coil: .009%
(For 0.5 volts RMS @ 1 kHz
Moving Magnet: 6.0 mV RMS
Moving Coil: 600
p V RMS
(A-weighted, relative to 0.5 V RMS)
Moving Magnet: -87dB
Moving Coil: -8OdB
(@1kHz)
Moving Magnet: 65 mV RMS
Moving Coil: 6.5 mV RMS
Nominal 47,000 ohms
Moving Magnet: 220
pF as supplied, user adjustable
Moving Coil: 100 ohm as supplied, user adjustable
(@1kHz)
Moving Magnet: +38.5dB
Moving Coil: +58.5dB
20Hz-20kHz,
$0.1 dB
6Hz- 1 50kHz, -3dB, into 1 Ok ohm load
8 volts RMS, 20Hz-20kHz
16
