Hafler P3000 - Front and Rear Panel Views; Front Panel View; Rear Panel View

– 2 –
Front Panel View
Rear Panel View
short
thermal
clipping
signal
channel 1
–15
–1
0dB
–10
–6
–3
channel 2
–15
–1
0dB
–10
–6
–3
nova
nova
trans
P3000
signal
clipping
thermal
short
• Use CH 1 Input ONLY
• Set CH 2 Gain to Max
• Set Output Level with
CH 1 Gain Control
A Division of Rockford Corp.
Tempe, AZ 85281 U.S.A.
Made in the U.S.A.
XLR Connections
3
21
+
–
Phone Connections
+
–
®
115V ~
60Hz
CH 1 (Mono)
CH 1
– +
4-8Ω
CH 2
– +
– +
Mono
P3000
250 V T4A
CAUTION: For continued
protection from risk of
fire, replace only with
same type and
rating of fuse.
CH 2
Audio Ground
Chass. Float
Mono 2-Ch
Mono Output:
8Ω 4-8Ω
WARNING: DO NOT REMOVE COVER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
PUSH
PUSH
