Hafler P3000 User Manual

– 10 –
P ARTS LIST
DESIGNATOR VALUE PART #
ALL RESISTORS IN OHMS, 1/4W
R1 56.2k RMP/4-5622
R2 1k RM/4-102C
R3 47k RM/4-473C
R4 47k RM/4-473C
R5 4.7k RM/4-472C
R6 1.07k RM/4-1071C
R7 909 RM/4-9090C
R8 200, Trim Pot RVH-201
R9 1k RM/4-102C
R10 28k RMP/4-2802
R11 10M RMP/4-106C
R12 28k RM/4-2802C
R13 470k RM/4-474C
R14 16 RM/4-160C
R15 3.3M RM/4-335C
R16 4.7k RM/4-472C
R17 10k RM/4-103C
R18 100k RM/4-104C
R19 604k RM/4-6043C
R20 45.3k RM/4-4532C
R21 2.2M RM/4-225C
R22 100k RM/4-104C
R23 100k RM/4-104C
R24 10k Pot RV-0818
R25 820 RM/4-821C
R26 2.2M RM/4-225C
R27 316 RM/4-3160C
R28 316 RM/4-3160C
R29 3.92k RM/4-3921C
R30 3.92k RM/4-3921C
R31 100 RM/4-101C
R32 100 RM/4-101C
R33 16 RM/4-160C
R34 470 RM/4-471C
R35 220 RM/4-221C
R36 1k RM/4-102C
R37 1k RM/4-102C
R38 3.3M RM/4-335C
R39 1k RM/4-102C
R40 3k RM/4-302C
R41 6.8k RM/4-682C
R42 10k RM/4-103C
R43 15k RM/4-153C
R44 10k RM/4-103C
R45 15k RM/4-153C
R46 47k RM/4-473C
R47 47k RM/4-473C
R48 15k RM/4-153C
R49 10k RM/4-103C
R50 4.7k RM/4-472C
R51 4.7k RM/4-472C
R52 15k RM/4-153C
DESIGNATOR VALUE PART #
R53 2.2M RM/4-225C
R54 10k RM/4-103C
R55 100k RM/4-104C
R56 15k RM/4-153C
R57 10k RM/4-103C
R58 100k RM/4-104C
R59 10k RM/4-103C
R61 100k RM/4-104C
R62 2.2M RM/4-225C
R63 28k RM/4-2802C
R64 100k RM/4-104C
R123 2k RM/4-202C
R124 820 RM/4-821C
R127 1k RM/4-102C
R128 100 RM/4-101C
R129 100 RM/4-101C
R130 1k RM/4-102C
R131 3k RM/4-302C
R132 3k RM/4-302C
R133 3k RM/4-302C
R134 100 RM/4-101C
R135 1k RM/4-102C
R136 200, Trim Pot RVH-201
R138 100 RM/4-101C
R139 470 RM/4-471C
R140 1k RM/4-102C
R141 470 RM/4-471C
R159 470 RM/4-471C
R164 220 RM/4-221C
TS1 Thermistor SS-1519-A
SW1 DPDT Switch SW-0280
C1 680pF, 100V CDS-681DBAA
C2 0.22µF, 50V CYV-224
C3 6800µF, 80V CERS-688D
C4 0.22µF, 250V CY-224AC
C5 6800µF, 80V CERS-688D
C6 270pF, 50V CDS-271CAAA
C7 270pF, 50V CDS-271CAAA
C8 4.7pF, 100V CDS-047DBAA
C9 0.1µF, 50V CDS-104CCDB
C13 470µF, 50V CER-477C-024
C14 470µF, 50V CER-477C-024
C15 0.1µF, 50V CDS-104CCDB
C16 0.1µF, 50V CDS-104CCDB
C17 0.1µF, 50V CDS-104CCDB
C18 0.1µF, 50V CDS-104CCDB
C19 0.1µF, 50V CDS-104CCDB
C20 0.1µF, 50V CDS-104CCDB
P3000U 120VAC, 60Hz
