Hafler P3000 User Manual

DESIGNATOR VALUE PART #
CR14 BAV99L Dual Diode SS-260SM
CR15 BAV99L Dual Diode SS-260SM
U1 TL072CD Dual Opamp SS-143SM
U2 TL072CD Dual Opamp SS-143SM
U4 LM339 Comparator SS-730SM
U5 LM339 Comparator SS-730SM
Power Switch SWH-1009
IEC Connector CC-0852
IEC Line Cord FAH-146
Dual Binding Post CC-0867
P3000 Transformer TT-1531
F2 Fuse, 1A Fast FS-1592
F3 Fuse, 1A Fast PS-1592
Line Fuse Fuse, 5A Slo Blo FS-005SB
DESIGNATOR VALUE PART #
C21 10µF, 16V CER-106SM
C22 10µF, 16V CER-106SM
C23 0.47µF, 50V CYV-474
C24 0.47µF, 50V CYV-474
C25 0.1µF, 50V CDS-104CCDB
C26 1µF, 50V CER-105C-024
C28 47µF, 16V CER-476-024
C29 10µF, 50V CER-106C-024
C30 0.1µF, 50V CDS-104CCDB
C31 0.1µF, 50V CDS-104CABB
C33 0.1µF, 50V CDS-104CCDB
C35 47pF, 200V CM-470-024
C36 22pF, 200V CM-200-024
C112 100µF, 25V CER-107A-024
C113 100µF, 25V CER-107A-024
C114 100pF, 50V CDS-101CAAA
C115 100pF, 50V CDS-101CAAA
C116 0.047µF, 50V CYV-473
C119 0.1µF, 100V CY-104
C120 0.1µF, 100V CY-104
Q1 MMBT3904LT1 SS-0792
Q2 LM-317 SS-239
Q3 LM-337 SS-240
Q4 2SK1058 SSH-741T
Q5 2SJ162 SSH-740T
Q6 MMBT5088L SS-0114
Q7 MMBT5088L SS-0114
Q8 MMBT3904LT1 SSS-0792
Q9 MPS-A56 SS-101A
Q10 MPS-A56 SS-101A
Q11 MPS-A06 SS-102A
Q12 MPS-A06 SS-102A
Q103 MMBTA06L SS-102SM
Q104 MMBT3906LT1 SS-0791
Q105 MMBT3906LT1 SS-0791
Q115 2SK1058 SSH-741T
Q116 2SJ162 SSH-740T
CR1 Red LED SS-741
CR2 Red LED SS-741
CR3 Red LED SS-741
CR4 Green LED SS-740
CR5 MMBD914L Diode SS-803SM
CR6 MMBD914L Diode SS-803SM
CR7 MMBD914L Diode SS-803SM
CR8 MMBD914L Diode SS-803SM
CR9 Bridge Rectifier 15A SS-0801
CR10 Bridge Rectifier 1.5A SS-0800
CR11 BAV99L Dual Diode SS-260SM
CR12 BAV99L Dual Diode SS-260SM
CR13 MMBD914L Diode SS-803SM
Parts List Modifications for
P1500U 120VAC, 60Hz
– 11 –
!
!
!
!
!
!
!
!
!
!
!
!
Components marked with this symbol are safety critical
and should only be replaced with identical components.
!
Los componentes marcados con el simbolo son
imprescindibles para la protección del equipo, por lo
cual que solo sean reemplazados por los mismos
componentes.
!
!
Les componsants marqués du symbole sont indis-
pensables à la sécuritée et ne peuvent être remplacés
qu'avec des composants identiques.
!
!
Bauteile, die mit einem gekenzeichnet sind, sind
sehr wichtig und dürfen nur mit den orginal Ersatzteilen
ausgetauscht werden.
!
!
I componenti contrassegnati da sono critici per la
sicurezza e devono essere rimpiazzati solo con ricambi
di valore identico.
!
C3 3300µF, 63V CERS-338E
C5 3300µF 63V CERS-338E
C35, 36 Not Used
CR9 Bridge Rectifier, 8A SS-0799
Q5, Q115 Not Used
P1500 Transformer TT-1456
Line Fuse Fuse, 4A Slo Blo FS-004SB
Parts List Modifications for P1500U 120VAC, 60Hz
European Linecord FA-1464
Fuseholder Cup 5x20mmFS-1125
1.25A Slo Blo 5x20mm FS-1474A
230V Transformer TT-1457B
Parts List Modifications for P1500CE
European Linecord FA-1464
Fuseholder Cup 5x20mmFS-1125
2.5A Slo Blo 5x20mm FS-1541A
230V Transformer TT-1532B
Parts List Modifications for P3000CE
!
!
!
!
!
!
!
!
!
!
!
