hager 4500 Series Electrical Supplemental Instructions

4500 Series Electric Lever Trim
Electrical Supplemental Instructions
Grade 1
I-ED00370
REV 3
Page 3 of 3
4. SECURE WIRES
A. After the exit device and trim is mounted, secure the wires in the back of exit device body with the self-adhesive ty-wrap mount
and ty-wrap.
5. TERMINATE WIRE
A. Terminate wire connections with appropriate crimp splices or wire nuts.
NOTE: It is helpful to stagger terminations. This allows for easy insertion of wires through prep holes.
27390028
STRAIN
RELIEF
