5
6LE007146A
• The fixed dates if the event needs to be repeated
every year on the same dates.
Press ok to confirm and the key to return to the
Daylight Savings Time menu.
Using keys 3/4 and ok, select the
relative dates of the start of the
daylight savings time period to be
enabled.
The examples opposite (the start
of Daylight Savings Time: 27
February and the end of Daylight
Savings Time: 23 October) are
configured as follows:
- possible values for the day: 01
to 31
- month: January . . . December
FIXED DATES
CUSTOM
RELATIVE
DATES
START OF DAYLIGHT
SAVINGS TIME
Day:
27
Month:
February
END OF DAYLIGHT
SAVINGS TIME
Day:
23
Month:
October
ASTRO
The Astronomical menu is used to precisely define
the geographic location of the project and thus
calculate the sunrise and sunset times automatically.
––––
ASTRO
DAYLIGHT
SAVINGS
TIME
WIRE INPUT
DATE
& TIME
BLUETOOTH
After selecting the Astro mode:
• Choose the A, B, C or D output concerned
• Choose the mode of the astronomical program:
- Sequential: the clock works automatically from
sunrise and sunset times.
- Specific: the clock works by combining the time
periods defined in the program, the sunrise and
sunset times and the brightness thresholds.
Press ok to confirm and the key to return to the
Astro menu.
D OUTPUTS
C OUTPUTS
ASTRO
LAT / LON
B OUTPUTS
SPECIFIC
OUTPUTS
A OUTPUTS
SEQUENTIAL
Fill in the data required for the clock to calculate the
sunrise and sunset times automatically.
• Set the latitude of the geographical area of the
project.
• Set the longitude of the geographical area of the
project.
• Set the time zone.
In the factory configuration, the latitude,
longitude and time zone correspond to
the coordinates of the city of Strasbourg
(France).
Press ok to confirm and the key to return to the
Astro menu.
Using keys 3/4 and ok, set:
- the latitude: the setting range
is 90°N (North) to 90°S (South);
- the longitude: the setting
range is 180°E (East) to 180°W
(West);
- the time zone: the setting
range is -12 h to +12 h with
respect to the Greenwich
meridian.
LAT / LON
OUTPUTS
Lat:
48° 35’ N
Lon:
07° 44’ E
TIME ZONE
GMT:
+1.00
CONTRAST
The Contrast menu is used to adjust the white level
of the screen.
RF
LINKS
ABOUT
Press ok to confirm and return to the Settings
menu.
CHANGING
SETTINGS
LANGUAGE
BACKLIGHT
CONTRAST
70%
–––––
Using keys 3/4,
increase or decrease
the contrast.
BACKLIGHT
The Backlight menu is used to set the brightness of
the screen and to enable (or disable) this function.
RF
LINKS
ABOUT
CHANGING
SETTINGS
LANGUAGE
BACKLIGHT
CONTRAST
–––––
To set the backlight brightness:
Press ok to confirm and return to the Backlight
menu.
10%
–––––
BACKLIGHT
IGNITION
80%
BRIGHTNESS
100%
Using keys
3/4, select
the brightness
percentage.
The screen backlight can be enabled temporarily or
permanently.
To temporarily enable the backlight:
Press ok to confirm and return to the Backlight
menu.
DISABLE
IGNITION
ENABLE
MANUAL
BRIGHTNESS
The backlight is enabled* after pressing a
key on the product and for a period of 20 s.
* when the product is supplied with 230 V ~.
To enable the backlight permanently:
Press ok to confirm and return to the Backlight
menu.
DISABLE
IGNITION
ENABLE
MANUAL
BRIGHTNESS
To disable the backlight:
Press ok to confirm and return to the Backlight
menu.
DISABLE
IGNITION
ENABLE
MANUAL
BRIGHTNESS
LANGUAGE
Select the desired language from the following:
FRANÇAIS, DEUTSCH, ENGLISH, NEDERLANDS,
PORTUGUES, ESPAÑOL, ITALIANA, ΕΛΛΗΝΙΚΗ,
SVENSKA.
RF
LINKS
ABOUT
CHANGING
SETTINGS
LANGUAGE
BACKLIGHT
CONTRAST
–––––
CHANGING SETTINGS
RF
LINKS
ABOUT
CHANGING
SETTINGS
LANGUAGE
BACKLIGHT
CONTRAST
–––––
The Changing Settings menu has several submenus:
• Reset BLE: to reset the Bluetooth
®
link security
code.
After this reset, your mobile device needs to
be re-paired with your clock.
Press ok to confirm and return to the Changing
Settings menu.
RETURN TO
PRODUCT FACTORY
CONFIGURATION
CHANGE
SETTINGS
RESET
RF LINKS
RESET
BLE
BLE RESET?
NO
YES
Using keys 3/4, select NO
or YES
• Reset RF links: to delete the existing settings and
RF links.
Press ok to confirm and return to the Changing
Settings menu.
RETURN TO
PRODUCT FACTORY
CONFIGURATION
CHANGE
SETTINGS
RESET
RF LINKS
RESET
BLE
RESET
RF LINKS?
NO
YES
Using keys 3/4, select NO
or YES
