Hagleitner XIBU - Tensioning Roller Spring

XIBU touchTOWEL
Tensioning roller spring
Spare part name:
XIBU HTR tension.roller.spring
Article no.
492011680000
Fig. 1 roller spring
Tools used:
XIBU key
Request:
Paper comes out of the dispenser crooked
(comes out one-sided).
Solution:
Replace the tensioning roller spring (missing).
Open the cover  hook the spring left and/
or right (Fig. 1 and 2).
Fig. 2
Fig. 3
32 | Tips & Tricks | January 2018
