44 | Tips & Tricks | January 2018
Installation of various XIBU dispenser on mirrors
Screw mounting of XIBU dispensers on mirrors
Mirror
Spacer
Recommendation for sizing:
Inner diameter: 5 mm
The hole in the mirror should be at least 4 mm larger than
the outside diameter of the spacer.
at least 2 mm
2 mm
When screw mounting a XIBU dispenser onto a mirror, the customer has to provide the neces-
sary spacers and recesses in the mirror.
Hagleitner does not give any warranty for the installation!
Spacer
