Hagleitner XIBU - Replacing the Cover Assembly


XIBU senseFOAM / XIBU senseDISINFECT / XIBU touchFOAM / XIBU senseDISHES
Replacing the cover assembly
Spare part name:
SE cover white XIBU
Article no.
492011575000
Fig. 1: Cover assembly, white
Fig. 2 Fig. 3
Slide the new cover into the guide on the
swivel joint and put back together in the re-
verse order.
Spare part name:
SE cover white XIBU touch
Article no.
492011765000
Spare part name:
DI cover white XIBU
Article no.
492011645000
XIBU senseDISINFECT
XIBU senseFOAM
XIBU touchFOAM
Spare part name:
XIBU senseDISHES cover
Article no.
492011895000
XIBU senseDISHES
Tools used:
Phillips screwdriver size PH1
Replacing the cover:
Open the dispenser with the XIBU key
 Loosen the screws on the left and the right
side of the cover, (Fig. 2 and 3) so that the
cover can be pushed back. (Fig. 3)
The cover can now be removed.
