Connection wire(Blacklight )
Service Manual
Model No.:
7-3 .Wiring Connection Diagram
NO. Name
1
2
3
4
Connection Wire(For Keyboard and Remote)
Connection Wire(For Speaker)
LVDS Wire
2
3
4
1
- 31 -
