Installation of outdoor unit
Try to bring the packed unit to the installation place.
When it is inevitable to unpack the unit, be careful not to damage the unit.
Wrap it with nylon etc.
After unpacking, be sure to put it with the front side of the unit facing up.
Note: When delivering, don't hold plastic
parts like inlet and outlet grill etc.
Selection of installation place
Place strong enough to support the unit and
will not cause vibration and noise.
Place where discharged wind and noise
doesn't cause a nuisan
ce to the neighbors.
Place where is less affected by rain or direct
sunlight and is sufficiently ventilated, or to
install a shield.
Place with enough space for smooth air flow.
Fixing of the unit
Fix outdoor unit using M10 bolt to concrete floor horizontally.
If installed on the wall or on top of a roof, bracket should be fixed securely to
resist earthquake or storms.
Use rubber pad during installation against unit vibration.
Facing up
Delivery
over 30cm
over 10cm
over
10cm
over
15cm
over 60cm
190
190 580
Installation dimension of outdoor unit (mm)
Installation procedures
