Haier AU182AFBEA - Main parts of electric control assembly; Main parts of PCB 0010451691

>a__WcU[S^ <[c >a`V[e[a`Wc
No part name specs QTY manufacturer part code
1 PTC PTH4295B 40Ω 1 Japan MURATA
2 fuse TLC-25A 25A/250V 1 SOC/TLNC-25A 001A4100010
G4F-11123T-US 12VDC OMROM
or JQ1a-12V PANASONIC
4 terminal block 1 JX-W-4P-B 300V 1
Jiangsu Wujin, Leqing
Huachen
5 module board MITSUBISHI module 30A 1 MITSUBISHI 001A4000114
6 radiator 1
7 rectifier 25A S25VB60 1
Japan
SHINDENGEN/American IR
8 rectifier 25A S15VB60 1
Japan
SHINDENGEN/American IR
9 PCB 0010451691 1
10 fan capacitor CBB61 2.5uF/500V 1
No part name specs QTY position manufacturer
1 fuse 42NM 1A 1 FUS2 Lite, Ningli
2 fuse 42NM 2.5A 1 FUS1 Lite, Ningli
TL-30145D 4 LED1,LED2,
WR022 yellow LED3,LED4
TL-30144D 1
WR022 green
5
Integrated
circuit
TLP521-1 2 O1,O2
6
Integrated
circuit
TLP741J 1 O3
7
Integrated
circuit
TD62003AP 1 U2
F3AA012E 12v 3
JQ1a-12V
9 connector B2B-XH-A 2PIN red 1 CN101
10 connector B2B-XH-A 2PIN white 1 CN107
11 connector B4B-XH-A 4PIN white 1 CN103
12 connector B4B-EH-A 4PIN white 1 CN102
13 connector B3B-XH-A 3PIN blue CN110
14 connector B10B-XH-A 10PIN white 1 CN105
15 connector B11B-XH-A 11PIN white 1 CN106
16 connector B2P3-VH 2PIN white 1 CN108
17 connector B2P4-VH 2PIN white 1 CN109
18 connector B3P5-VH 5PIN white 1 CN112
19 connector B2P-VH 2PIN white 1 CN5
20 connector B2P-VH 2PIN red 1 CN6
21
switch
transformer
BCK-8-F403G 1 T1
22 resistance 550NR-14D S14KV350 1 Z302
Beijing
Guoxing
Main parts of PCB 0010451691
8 relay RL1,RL2,RL3
4 LED LED5
3 LED
AU092AABHA, AU122AABHA:
3 reactor 1 001A1431404
Main parts of electric control assembly
-258-
