Haier H2F-220WSAA User Manual

10
FUNCTIONS
English
Insertion into a row of kitchen units
min.
300cm
580
630
min.50
2
The appliance can be inserted into a row of kitchen units. To match the appliance to the height of
the row of the units, a suitable stack cabinet can be added. When inserting the appliance into a row
of standard kitchen units (max. depth 580 mm), the appliance can be installed directly next to the
kitchen unit. The appliance door projects relative to the front of the kitchen unit by 34mm at the
side and by 55mm in the middle of the appliance. It can be opened and closed perfectly as a result.
Important for the ventilation:
At the back of the stack cabinet, there has to be a ventilation duct of at least 50mm depth
throughout the width of the stack cabinet.
The ventilation space under the ceiling has to be at least 300cm².
The larger the ventilation space, the more energy-saving the appliance is in operation.
If the appliance is installed with the hinges next to a wall, the distance between appliance and wall
has to be at least 55mm. This corresponds to the projection of the handle when the door is open.
min.
300cm
2
min.50
630
580

Haier H2F-220WSAA Specifications

General

Door hinge	Right
Control type	Touch
Display type	LED
Product type	Upright freezer
Product color	White
Built-in display	Yes
Shelves material	Plastic
Appliance placement	Freestanding
Freezer number of shelves/baskets	2
Icemaker	No
Noise level	40 dB
Star rating	4*
Climate class	SN-T
Freezing capacity	18 kg/24h
Freezer net capacity	226 L
Freezer gross capacity	237 L
Operating temperature (T-T)	10 - 43 °C
Storage time during power failure	7 h
Current	1.5 A
Connected load	150 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	230 kWh
Warranty period	2 year(s)
Control position	External
Package depth	739 mm
Package width	647 mm
Package height	1734 mm
Package weight	77300 g

Weight and Dimensions

Depth	660 mm
Width	595 mm
Height	1671 mm
Weight	69000 g
