Haier H2F-220WSAA User Manual

9
FUNCTIONS
English
Freezer functions
FAST FREEZING:
Press the button A3 to choose the “S.FRZ” function, then press the button A4, you can
activate fast freezing of fresh food.
The dedicate light E switches on to indicate that the function is on, and activation of the function is
achieved.
light will be on till function will be disabled.
For fast freezing a small amount of food, this function is recommended to be activated 2 hours before
inserting food; if you have a large amount of food to freeze at one time, it is recommended that the function
be activated 24 hours before inserting food Function will stop automatically after 24 hours or manually.
Power consumption will increase when this function is on.
FUNCTION ECO:
When the screen is unlocked, press the button A3 to choose the “ECO” function, then
press the button A4, you can activate the function of energy saving, setting temperature within the range of
-18°C and -14°C. If the temperature has been set at -19°C or lower, it will be set automatically at -18°C when
the ECO function is on.
If this function is activated, led D will be on till the function will be unable.
You can press the button A3 to choose the “ECO” function, then press the button A4 to disable the function.
ECO function and Fast Freezing function can not be used simultaneously.
Child Lock:
When the screen is unlocked, press the button A3 to select the Child Lock function and then
press the button A4, the function will be on. Unlock: Touch any button on the screen, the display screen and
the child lock button will be lightened; press the button A3, the child lock button flickers; press the button
A4, the screen will be unlocked.
When the screen is locked, the button A2 is not effective; function selection is not available when pressing
the button A3; power can be turned off by press the button A4 for 5 sec.
Alarm signals
TEMPERATURE ALARM:
if temperature inside freezer is over -8°C, an intermittent buzzer and the flashing
led F will indicate the temperature alarm. Display will show you code HH
After the screen is unlocked, press the button A3 to choose the “Alarm” function, then press the button A4,
it’s possible to stop acoustic sign, but alarm condition will continue till internal temperature will be colder
than -12°C.
DOOR ALARM:
If the door is left open for 60 seconds, the anomalous condition will be notified by
intermittent buzzer. The alarm condition will stop by closing the door or by pressing button to select Alarm
function and pressing the OK button, but in this second case alarm condition will restart after 60 seconds if
door is still open. If the door is open for consecutive 7 minutes, the inner light will be off and there will be
continuous alarm.
FAULTY ALARM:
Code F4 on display together with alarm led F flashing will indicate a faulty condition of
freezer, but there is no danger for temporary food preservation.
Code Ed on display together with alarm led F flashing and acoustic signal, will indicate a grave faulty
condition of freezer that must be switched off.
For both faulty conditions you must call after sales service as soon as possible.

Haier H2F-220WSAA Specifications

General

Door hinge	Right
Control type	Touch
Display type	LED
Product type	Upright freezer
Product color	White
Built-in display	Yes
Shelves material	Plastic
Appliance placement	Freestanding
Freezer number of shelves/baskets	2
Icemaker	No
Noise level	40 dB
Star rating	4*
Climate class	SN-T
Freezing capacity	18 kg/24h
Freezer net capacity	226 L
Freezer gross capacity	237 L
Operating temperature (T-T)	10 - 43 °C
Storage time during power failure	7 h
Current	1.5 A
Connected load	150 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	230 kWh
Warranty period	2 year(s)
Control position	External
Package depth	739 mm
Package width	647 mm
Package height	1734 mm
Package weight	77300 g

Weight and Dimensions

Depth	660 mm
Width	595 mm
Height	1671 mm
Weight	69000 g
