Haier HL42XK1 User Manual

A A
B B
C C
D D
E E
4 4 3 3 2 2 1 1
1.25 x (1+180/110) = 3.3V
1.25 x (1+100/100) = 2.5V
POWER SUPPLY +5V FOR TUNER
1.25 x (1+0/100) = 1.25V
10% tolerance
FOR MT8292 9V
POWER SUPPLY +30V FOR SAMSUNG TUNER
32/48KHz
NC
AV33 +5V GND AV12 +5V_TUNER AV25 +12V +9V
OPWM2
OPWM2
+30V_TUNER
GND1,2,4,5,6,7,8,9,10,11,12,13,14,15 +5V1,2,4,5,8,9,10,15 AV332,5,8,9,10,13 AV125,8,10 +5V_TUNER5 AV255,12 +12V1,9,15 +9V14
OPWM24,7
+5V
AV33 AV25+5V
+5V_TUNER+9V
AV12
AV25
+9V+12V
+5V_TUNER
+30V_TUNER
R12 110_1% R0603/SMD
U9
7805 TO-263-3/SMD
1
2
3
IN
GND
OUT
R436 NC/2K
D22 NC/NS/1N4148
+
CE234 NC/220uF/35V C220UF10V/D6.3H7
D20 NC/1N4148
C539 NC/1uF/50V C0603/SMD
CB32 0.1uF C0402/SMD
+
CE96 220uF/16V C220UF10V/D6.3H7
Q16 NC/2N3904
1
3 2
CB228 0.1uF C0402/SMD
R14 180_1% R0603/SMD
CB197 0.1uF C0402/SMD
R19 0 R0603/SMD
C540 NC/330pF C0402/SMD
C575 1uF C0402/SMD
+
CE19 47uF/16V C47UF16V/D5H7
CB229 0.1uF C0402/SMD
+
CE22
100uF/16V C100UF16V/D6.3H7
C573 1uF C0402/SMD
+
CE83
100uF/16V C100UF16V/D6.3H7
+
CE30
100uF/16V C100UF16V/D6.3H7
+
CE28 100uF/16V C100UF16V/D6.3H7
U7 AZ1117/adj
SOT223/SMD
1
23
ADJ/GND
OUTIN
U37 BA178M09FP TO-252-3/SMD
2
31
ADJ/GND
OUTIN
C538 NC/1uF
U41 AZ1117/adj
SOT223/SMD
1
23
ADJ/GND
OUTIN
C537 NC/330pF
R439 NC/0R
+
CE224
220uF/16V C330UF10V/D6.3H7
C574 1uF C0402/SMD
C324 1uF C0603/SMD
+
CE592 100uF/16V C100UF16V/D6.3H7
CB18 0.1uF C0402/SMD
L13
NC/1000uH L/DU1311/SMD
R71 110_1% R0603/SMD
D17
NC/UDZS33
1 2
R70 110_1% R0603/SMD
CB398 0.1uF C0402/SMD
CB23 0.1uF C0402/SMD
U10 AZ1117/adj
SOT223/SMD
1
23
ADJ/GND
OUTIN
C572 1uF C0402/SMD
R17 100 R0603/SMD
