Haier hlp140e User Manual

14
3. Set Cycle and Start
To start drying a laundry load using Auto Dry with presets for Temperature and Time,
there are 3 easy steps:
1. Turn ‘Power ON’ 2. Choose drying Cycle –
Normal, Heavy or Delicate
3. Press ‘Start’
Normal , Heavy and Delicate Cycles are auto-set for Temperature and Time to dry a regular load.
Timed Dry Cycle is for manual selecting Dry times and Temperatures. (See next page for instructions)
5. End Dry Cycle
A beeper alarm alerts you when the Drying Cycle ends, then the dryer will power down.
Take out the clothes as soon as possible.
OPERATING INSTRUCTIONS
4. Cooling Status.
When ‘Cooling’ Status LED is ON, the Cooling down time takes 10 minutes for dryer along with the
garments.
If you want to take out clothes in the middle of drying cycle, please use caution and carefully
take out the HOT clothes.
6. Clean Filter
‘Clean Filter’ Status LED reminder goes ON. After drying each load of clothing, always clean
the lint filters.
Note
Cycles
Dry
Time
Temp
Start
Pause
Power
On/Off
Dry
Cooling
End Cycle
Clean Filter
Normal
Timed Dry
Heavy
Delicate
30
60
90
120
High
Low
Air-Dry
150
Status
A
U
T
O
D
R
Y
1
2
3
Power
On/Off
Cycles
Start
Pause
Quick Start
Normal , Heavy and Delicate Cycle Laundry Loads
Exhaust vent
Casing

Haier hlp140e Specifications

General

AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Annual energy consumption	400 kWh
Door hinge	Left
Drum volume	73.62 L
Control type	Touch
Loading type	Front-load
Product color	White
Built-in display	No
Appliance placement	Freestanding
Cycle time	150 min
Drum capacity	2.6 kg
Number of cycles	4
Package depth	482.6 mm
Package width	722.2 mm
Package height	780 mm
Package weight	28123 g
LED program stage indicator	Yes

Weight and Dimensions

Depth	425 mm
Width	630 mm
Height	685 mm
Weight	24766 g
