Haier hlp140e User Manual

8
SET UP INSTRUCTIONS
5. Venting The Dryer
Proper venting of the dryer is very important. Determine the best and safest ducting for the dryer.
Correct
Incorrect
Outside
Vent
Use a metal or UL vent.
Do not use plastic ducting.
Do not crimp or use excessive ducting.
Clean old ducts before installing this dryer.
WARNING!
!
Venting must conform to local building codes.
Do not use thin plastic or foil ducting.
Use 4 inches (10.2cm) diameter rigid or flexible metal duct (note: venting materials are not
supplied with the dryer, and you should obtain the venting materials necessary for proper
installation).
Position the Dryer such that the exhaust duct run is as short as possible. Make sure
there is no more than 6 feet of exhaust ducting.
Clean old ducts before installing this dryer
Never bend or collapse ducting flex hose. Use few elbows joints as needed.
Use duct tape on all duct joints.
Insulate ductwork that runs through unheated areas in order to reduce condensation and lint
build-up on pipe walls.
Exhaust Requirements and Maintenance.
PLEASE BE AWARE THAT FAILURE TO EXHAUST THE DRYER
CORRECTLY WILL VOID THE DRYER’S WARRANTY.
WARNING
!
To reduce the risk of fire and combustion, the dryer must be vented outdoors.
Lint accumulation can cause fires.
Check and clean vents and ducting as often as possible.

Haier hlp140e Specifications

General

AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Annual energy consumption	400 kWh
Door hinge	Left
Drum volume	73.62 L
Control type	Touch
Loading type	Front-load
Product color	White
Built-in display	No
Appliance placement	Freestanding
Cycle time	150 min
Drum capacity	2.6 kg
Number of cycles	4
Package depth	482.6 mm
Package width	722.2 mm
Package height	780 mm
Package weight	28123 g
LED program stage indicator	Yes

Weight and Dimensions

Depth	425 mm
Width	630 mm
Height	685 mm
Weight	24766 g
