Screw mounting hook bracket and wall spacer to dryer with screws provided.
Connect vent housing to dryer using hose clamp provided to the exhaust pipe.
1.Attach Hanging hook bracket using
the 4 screws.
2.Attach the 2 wall spacers to the bottom
of the dryer, using the 2 screws.
3.Attach Exhaust Housing
7
SET UP INSTRUCTIONS
Exhaust Pipe
Hose Clam
Exhaust Vent Housing
4. You have two choices of the exhaust pipe housing direction
Assemble Dryer for Installation

Haier hlp140e Specifications

General

AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Annual energy consumption	400 kWh
Door hinge	Left
Drum volume	73.62 L
Control type	Touch
Loading type	Front-load
Product color	White
Built-in display	No
Appliance placement	Freestanding
Cycle time	150 min
Drum capacity	2.6 kg
Number of cycles	4
Package depth	482.6 mm
Package width	722.2 mm
Package height	780 mm
Package weight	28123 g
LED program stage indicator	Yes

Weight and Dimensions

Depth	425 mm
Width	630 mm
Height	685 mm
Weight	24766 g
