Haier hlp140e User Manual

Exhaust
vent casing
Lint
filter
Exhaust
Filter
The filter is in the rear
of the drum
Do not put water directly on dryer.
Do not use thinner, gasolene or alcohol.
Do not use any type of spray cleaner to clean the interior.
Remove everything from drum before drying the next load.
Clean cabinet with mild soap and water only. Do not use
harsh or abrasive cleaners, as this could damage the dryer.
Clean buildup such as lint on filters after each use, otherwise it will affect
the performance of your dryer.
1. Remove the Exhaust venting casing
containing the filters.
Use four finger grabbing holes in middle of the
exhaust vent casing center to pull from the drum.
Remove the filters by pulling straight out.
The exhaust vent casing contains the ‘Lint
filter’ and ‘Exhaust filter’, as shown in figure 1.
3. Install the filters
After cleaning the filters, assemble filters in the
order of
‘exhaust vent casing’,’lint filter’ and
‘exhaust filter’
(as shown in figure 3).
2. Cleaning the filters from lints
Separate ‘exhaust vent casing’,’lint filter’ and ‘exhaust
filter’ and clean the lint off the filter and exhaust filter
with a soft brush or a small vacuum cleaner. (as shown
in figure 2) or wash it with water if still dirty.
Dry completely before use and do not damage the filters.
The lint filter must be always used for drying.
It must be cleaned each time before or after each use.
Cleaning of Lint trap and Filters
Figure 3
Care And Cleaning Guide
brush Lint
small vacuum
Cleaner
Figure 2
Figure 1
Clean the interior drum or dryer housing with a damp
soft cloth.
Lint Filter Exhaust Filter
2LO
7KLQQHU
%HQ]HQH
NEVER USE YOUR DRYER WITHOUT
THE LINT FILTERS INSTALLED.
18
Exhaust
vent casing
Please unplug the power cord when cleaning the Dryer.
4. Align the recesses center of the ‘exhaust vent
casing’
to the center of drum and make sure that
it is firmly inserted.
!
WARNING
!
.

Haier hlp140e Specifications

General

AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Annual energy consumption	400 kWh
Door hinge	Left
Drum volume	73.62 L
Control type	Touch
Loading type	Front-load
Product color	White
Built-in display	No
Appliance placement	Freestanding
Cycle time	150 min
Drum capacity	2.6 kg
Number of cycles	4
Package depth	482.6 mm
Package width	722.2 mm
Package height	780 mm
Package weight	28123 g
LED program stage indicator	Yes

Weight and Dimensions

Depth	425 mm
Width	630 mm
Height	685 mm
Weight	24766 g
