SERVICE MANUAL
Model: HRF-628AF6/IF6
11
Issue 2013-04-07
REF. Ref1304S001V0
5. Remove the foam and you could change the damper.
3.6 Evaporator cover disassembly
1. Remove the screw cover;
.
2. Remove one screw, remove the cover with the sucker;
3. Disconnect the cable and remove the support;
