Haier HRF-628AF6 User Manual

SERVICE MANUAL
Model: HRF-628AF6/IF6
5
Issue 2013-04-07
REF. Ref1304S001V0
Chapter 2 Product Feature
2-1. Specifications
Model HRF-628AF6 HRF-628IF6
1. Product identification
Description of appliance Side By Side Side By Side
Type of appliance(FS = free standing, BI = built-in) FS FS
Supplier own brand Haier Haier
2.
Basic features
Climate class
(SN=10~32°C, N=16~32°C, ST=18~38°C, T=18~43°C)
SN.N.ST SN.N.ST
Gross capacity l 610 610
Total net capacity l 550 550
Net capacity refrigerator compartment l 375 375
Net capacity freezer compartment (total) l 175 175
Freezing capacity kg/24 h 10 10
Energy consumption kWh/year 420 420
Energy consumption (EN153) kWh/24 h 1.15 1.15
Max storage time by power failure（Freezer）
h 5 5
Refrigerant R600a/80g R600a/80g
3. Control panel
External control display LED LED
Temperature range (from>to) °C
(Fridge)9~1°C/
(freezer)-24~-14°C
(Fridge)9~1°C/(fre
ezer)-24~-14°C
Super Cooling (Fridge) YES YES
Super Freezing (Freezer) YES YES
Stand-by function (Holidays) YES YES
4.
Basics datas
Voltage / frequency 220/50 220/50
Input power / mains fuse (intensity) W /A 180/1.8 180/1.8
Lenght of cable/incl. plug cm 349 349
5. Packing dimensions
Unit dimensions without handle ( H / W / D) mm 1790*908*690 1790*908*690
Net weight kg 120 120
Packing dimensions (H / W / D) mm 1902*980*760 1902*980*760
Gross weight kg 137 137
AGORA - CONFIDENTIAL - AGORA
Downloaded / printed on Agora software : 16/03/2021
by customer : ADEPEM 75010
AGORA - CONFIDENTIAL - AGORA

Haier HRF-628AF6 Specifications

General

Product color	Aluminium, Stainless steel
Product design	American door
Built-in display	-
Appliance placement	Freestanding
Number of compressors	1
Icemaker	Yes
Noise level	42 dB
Climate class	SN-ST
Total net capacity	550 L
Total gross capacity	610 L
Multi-airflow system	No
Lamp type	LED
Fridge net capacity	375 L
Fridge gross capacity	- L
Fridge number of shelves/baskets	4
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	175 L
Storage time during power failure	- h
Connected load	- W
AC input frequency	50 Hz
Annual energy consumption	420 kWh
Package depth	760 mm
Package width	980 mm
Package height	1900 mm
Package weight	135000 g

Weight and Dimensions

Depth	690 mm
Width	910 mm
Height	1790 mm
Weight	122000 g
