Haier HW70-B12636N User Manual

3-Control panel
GB
10
3.5.4 Function button“Extra rinse“
Press this button (Fig. 3-10) to rinse the laundry more
intense with fresh water. This is recommended for
people with sensitive skin.
By pressing the button several times one to three ad
-
ditional cycles can be selected. They appear in the dis
-
play with P--1/P--2/P--3.
3.5.5 Function “Speed up“
This function saves time and energy. Preferable if laun-
dry is slightly soiled. Press simultaneously button
“Extra
rinse“ and ”Delay” (Fig. 3-11) for about 3 seconds
to activate the “Speed up” function;
SPEEd
uP is dis
-
played. This function is not available in all programmes
(see PROGRAMMES).
3.7 “Start/Pause“ button
Press this button (Fig. 3-13) gently to start or inter
-
rupt the currently displayed programme. During pro
-
gramme setting and during programme run the LED
above the button is shining, or if interrupted blinking.
3.6 Function button “Delay”
Press this button (Fig. 3-12) to start the programme
with a delay. End time delay could be increased in steps
6:30 means
end of programme cycle will be in 6 hours and 30 minut-
es.Press “Start/Pause” button to activate delay. It is not
applicable to programme Spin,Eco 40-60.
Note: Liquid detergent
If using liquid detergent, it is not recommended to activate the end time delay.
3.8 Child lock
Press button “Temp.“ and ”Steam” (Fig. 3-14) for 3
seconds simultaneously to block all panel elements
against activation. For unlocking please press again
the two buttons.
The display shows cLo
I-
(Fig. 3-15) if a button will be
pressed, when the child lock is activated. The change
is not running.
3-15
Extra rinse
3-10
Delay
Extra rinse
Speed up
3-11
Delay
3-12
Start/Pause
3-13
3-14
Temp.
Speed Steam
Steam
3-9
If “Temp.” button is pushed the “Steam” function will be
deactivated.You can activate “Steam” function only bef-
ore to start any programme. You cannot activate “Steam”
-
function while the appliance is already executing a programme.
(add time to the original
programme time).

Haier HW70-B12636N Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Drum volume	45 L
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Amber
Appliance placement	Freestanding
Drum capacity	7 kg
Cycle time (max)	206 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1200 RPM
Noise level (spin)	67 dB
Number of washing programs	16
Add garment (pause) function	No
Annual water consumption washing	9000 L
Annual energy consumption washing	106 kWh
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	41 L
Energy consumption washing per cycle	- kWh
Package depth	565 mm
Package width	650 mm
Package height	890 mm
Package weight	70000 g

Weight and Dimensions

Depth	510 mm
Width	590 mm
Height	850 mm
Weight	64000 g
