11.1 Additional technical data
zH05/~V 042-022V ni egatloV
01A ni tnerruC
0002W ni rewop .xaM
Water pressure in MPa
gk ni thgiew otteN
3
This product meets the requirements of all applicable EC directives with the correspon-
ding harmonised standards, which provide for CE marking.
HW100 HW90
HW80
HW70
74
72
64
74
Note: The exact height of your washer is dependent on how far the feet are extended from
the base of the machine. The space where you install your washer needs to be at least
40mm wider and 20mm deeper than its dimensions.
TOP VIEWWallFRONT VIEW
A
B
E
D
C
HW100 HW90 HW80 HW70PRODUCT DIMENSIONS
B Overall width of product mm
A
Overall height of product mm
C Overall depth of product
(To main control board size) mm
D Depth of door open mm
E Minimum door clearance
to adjacent wall mm
11.2 Product dimensions
850 850 850 850
595 595 595 595
600 600 550 460
1100 1100 1050 960
400 400 400 400
