3. Input/Output Specification
3.1 Input Signal Connector
HDMI
Pin No. Description Pin No. Description
1
T
MDS Data2+ 11
T
MDS Clock Shield
2
T
MDS Data2 shield 12
T
MDS Clock-
3
T
DMS Data2- 13 CEC
4
T
MDS Data1+ 14 Reserved (N.C. on device)
5
T
MDS Data1 shield 15 SCL
6
T
MDS Data1- 16 SD
A
7
T
MDS Data0+ 17 DDC/CEC Ground
8
T
MDS Data0 shield 18 +5V Power
9
T
MDS Data0- 19 Hot Plug Detec
t
10
T
MDS Clock+
