8. Block Diagram
MSD8560VX / U400
DDR3 4Gb
/U405
DDR3 4Gb
/U404
eMMC 8GB/U406
HDMI 2
/CN500
HDMI 1[MHL]
/CN501
HDMI 3
/CN502
USB2.0
/CN105
WiFi
/CN106
USB3.0
/CN107
YPbPr RL[AV]
/CN100
LAN
/CN108
DVB-T2 Demod
/U111
Tuner
/TU100
LVDS 2 LINKs
/CN401
Audio Amp
/U600
SPDIF
/CN102
AVout
/CN101
Headphone
/CN111
