10
Half Scart
3.2 Input Signal Timing
RGB
Item H.Freq. (KHz) Mode Resolution V.Freq. (Hz)
1 31.469 IBM VGA 12H 640x480 59.940
2 35.156 VESA 800x600 56.250
3 37.879 VESA 800x600 60.317
4 48.363 VESA 1024x768 60.004
5 44.772 1280x720 59.855
6 47.776 CVT 2.3MA 1280 x768 60
7 47.7 VESA 1360x768 60
8 63.981 VESA 1280x1024 60.020
9 66.587 VESA reduced blanking mode 1920x1080 60.0
Pin No.
Signal
Pin No.
Signal
1 Audio output B ( right ) 12 Comms data 1
2 Audio input B ( right ) 13 Ground
3 Audio output A ( left ) 14 Ground ( blanking )
4 Ground (audio ) 15 Chorma input
5 Ground 16 ---
6 Audio input A ( left ) 17 Ground ( video input & output )
7 --- 18 Ground
8 Function select 19 Video output ( composite )
9 Ground 20 Video input ( composite or Y)
10 Comms data 2 21 Common ground ( shield )
11
---
