Haier LT32F6 Service Manual

11
HDMI
Item
1920X1080P
50Hz
1920X1080P
25Hz
1920X1080i
50Hz
1280X720P
50Hz
720X576P
50Hz
720X576i
50Hz
Pixel rate
148.5MHz
(6.734 ns)
74.25MHz
(13.468 ns)
74.25MHz
( 13.468ns )
74.25MHz
(13.468 ns)
27 MHz
(37.037 ns)
13.5MHz
( 74.074 ns )
Horizontal
Frequency
56.25 KHz 28.125 KHz 28.125 KHz 37.5 KHz 31.25 KHz 15.625 KHz
Active
1920 pixels
(12.929 us)
1920 pixels
(25.859 us)
1920 pixels
(25.859 us)
1280 pixels
(17.239 us)
720 pixels
(26.667 us)
720 pixels
(53.333 us)
Blank
720 pixels
(4.848 us)
720 pixels
(9.697 us)
720 pixels
( 9.697 us )
700 pixels
(9.428 us)
144 pixels
(5.333 us)
144 pixels
( 10.667 us )
Period
2640 pixels
(17.778 us)
2640 pixels
(35.556 us)
2640 pixels
( 35.556 us )
1980 pixels
(26.667 us)
864 pixels
(42.000 us)
864 pixels
( 64.00 us )
Pulse delay
528 pixels
(3.556 us)
528 pixels
(7.111 us)
528 pixels
(7.111 us )
440 pixels
(5.926 us)
12 pixels
(0.444 us)
12 pixels
( 0.889 us )
Pulse width
44 pixels
(0.296 us)
44 pixels
(0.593 us)
44 pixels
( 0.593 us )
40 pixels
(0.539 us)
64 pixels
(2.370 us)
63 pixels
( 4.667 us )
Vertical
Frequency
50 Hz 25 Hz 50 Hz 50 Hz 50 Hz 50 Hz
Active
1080 lines
(19.2 ms)
1080 lines
(38.4 ms)
1080 lines
( 38.4 ms )
720 lines
(19.2 ms)
576 lines
(18.442 ms)
576 lines
( 36.864 ms )
Blank
45 lines
(0.8 ms)
45 lines
(1.6 ms)
45 lines
(1.6 ms )
30 lines
(0.8 ms)
49 lines
(1.568 ms )
49 lines
(3.136 ms )
Period
1125 lines
(20 ms)
1125 lines
(40 ms)
1125 lines
( 40 ms )
750 lines
(20 ms)
625 lines
(20.000 ms)
625 lines
( 40 ms )
Pulse delay
4 lines
(0.071 ms)
4 lines
(0.142 ms)
2 lines
( 0.071 ms )
5 lines
(0.133 ms )
5 lines
(0.160 ms)
2 lines
( 0.128 ms )
Pulse width
5 lines
(0.089 ms)
5 lines
(0.178 ms)
5 lines
(0.178 ms )
5 lines
(0.133 ms)
5 lines
(0.160 ms)
3 lines
(0.192 ms )
Scan Progressive Progressive Interlace Progressive Progressive Interlace
Sync type
ACS / HDTV
w/serr & eq
ACS / HDTV
w/serr & eq
ACS ACS
Video kind
Analog
YPbPr
(ITU-R
BT.709)
Analog
YPbPr
(ITU-R
BT.709)
Analog
YPbPr
(SMPTE
RP177)
Analog
YPbPr
(SMPTE
RP177)
